| Parameter | Specification Details |
|---|---|
| Pipe diameter applicable | DN50-600 (φ 60-610) |
| Conveying length | ≥ 500MM |
| Line length | 7.5M (or it depends on situation) |
| Line height | 800MM |
| Trolley system | 2 sets / 1 set |
| Moving up/down | With screw lifter, manually (A1\A2) / electrically (A3\A4) |
| Bracket system | Supporting rotator (A1\A3) / with rolling roller (A2\A4) |
| Material of the roller | Carbon steel with blue treated surface (coated with rubber if necessary) |
| Lengthwise moving | Moving manually |
| Max loading capacity | 1000KG |
| Track length | 7.5M (or it depends on situation) |
| Track section | 3 pieces |
| Track type | Square-steel + channel-steel + supporting feet height adjustable |
Standing in the customers' shoes.
Client satisfaction is the lowest standard.
Professional, comprehensive, and detailed support.
To quickly and efficiently resolve all after-sales issues raised by clients without being limited by conditions of costs.
A: We are a factory-based trading company.
A: Generally it is 30-40 days if the goods are in stock. Or it is 60-80 days if the goods are not in stock, which depends on the quantity.
A: Payment ≤ 1000USD, 100% in advance. Payment ≥ 1000USD, 40% T/T in advance, and the balance before shipment.
A: The applicable pipe diameter for the system is DN50-600 (φ 60-610).
A: The maximum loading capacity of this conveying and trolley system is 1000KG.
A: The height adjustment is operated with a screw lifter, either manually (A1\A2 models) or electrically (A3\A4 models).
