| Classification | Specifications & Parameter Details | Functionality & Capabilities | |
|---|---|---|---|
| Solution Introduction | DWS Parcel Pulling Section | Adjust parcel posture to ensure it enters the weighing section at a suitable angle | |
| DWS Single-scale Weighing Section | Automatically complete weight detection and record data | ||
| DWS Buffer Section | Information processing of scanned items | ||
| DWS Six-sided Scanning System | Barcode identification and automatic collection | ||
| Solution Working Parameters | Speed | 1.5 ~ 2m/s | |
| Parcel Control Spacing | 1000mm | ||
| Efficiency | 6000 pieces/hour | ||
| Parcel Position | No Requirement | ||
| Field of View | No Blind Area | ||
| Weighing Performance | Weighed Object Weight (kg) | ≤50 | |
| Measurement Accuracy (g) | ±20 | ||
| Precision Level | Class III | ||
| Applicability | Suitable Parcel Size | W100×L100×H50 - W800×L1500×H700 | Various parcels with flat surface waybills |
| Unsuitable Types | Highly-reflective and highly transparent parcels (may affect accuracy) | Severely damaged or wrinkled surfaces, highly reflective packaging, excessively sticky magnets, and cylindrical or spherical parcels | |
| Identification Performance | Code Reading Performance | Barcode Identification: Minimum Width 0.25mm | Barcode Types: 1D Code (Code128/Code39/EAN), 2D Code (QR2/DM) |
| Barcode Reading Rate | ≥99% | ||
| Image Recording Resolution | 4000×3000 | ||
| Optional Volume Performance | Optional Brand: Hikvision/Huarui | Accuracy: ±10mm | |
