| No. | Spare Part Name | Specification | Number | Usage Part |
|---|---|---|---|---|
| 1 | Synchronized feather belt | 5M×320×10 | 2 piece | Fur brush fracture |
| 2 | Synchronized feather belt | 5M-295-10 | 2 piece | Driver label convey fracture |
| 3 | Synchronized feather belt | 5M-460×15 | 2 piece | Knife-plate |
| 4 | Art design blade | 9×80 φ3 | 20 piece | Knife-plate fracture |
| 5 | Mid-relay | - | 3 | - |
| 6 | Tool attached machine | - | 1 set | - |
| 7 | Fur brush | Silica gel bar | 10 meter | Fur brush fracture |
| NO. | Component Name | Brand | Manufacturer |
|---|---|---|---|
| 1 | SUS304 stainless steel | - | South Korea |
| 2 | Electric motor | TWT | Taiwan |
| 3 | Bearing | NSK / MNB / EZO / IJK | Japan |
| 4 | Servo Motor | Panasonic | Japan |
| 5 | Servo driver | Panasonic | Japan |
| 6 | PLC programmable controlling machine | Panasonic | Japan |
| 7 | Frequency converter | TELTA | Taiwan |
| 8 | Touch screen | WEINVIEW | Taiwan |
| 9 | Contactor | SCHNEIDER | France |
| 10 | Transducer | SUNX | Japan |
| Module Name | Electric Appliance Name | Type | Qty | Merchant | Place of Production |
|---|---|---|---|---|---|
| Machine frame fluctuation unit | Low power a-c dynamo | 5IK90GU-CF-5GU30KB | 1 | ORT / TWT | Taiwan |
| Clean-down unit | Low power a-c dynamo | 5IK120A-CFT | 1 | ORT / TWT | Taiwan |
| Feeding unit | Low power a-c dynamo | RV50-15K-180 | 1 | ORT / TWT | Taiwan |
| - | Frequency converter | VFO-0.25KW | 1 | Schneider | France |
| - | Photoelectricity inductor | CX-421 | 1 | Panasonic | Japan |
| Bottle Carrying unit | Low power a-c dynamo | 5IK90GN-YFT-5GN20K | 1 | ORT | Taiwan |
| - | Frequency converter | VFO-0.25KW | 1 | Schneider | France |
| Bottle Separation unit | Low power a-c dynamo | 5IK90GN-YF-5GN10K | 1 | ORT | Taiwan |
| - | Frequency converter | VFO-0.25KW | 1 | Schneider | France |
| Hairbrush unit | Low power a-c dynamo | 4IK25GN-CFT-4GN3K | 2 | ORT | Taiwan |
| Cutter head unit | Cutter head servo motor | MHMD042P1U (400w) | 1 | Panasonic | Japan |
| - | Cutter head servo driver | MBDDT2210003 (400w) | 1 | Panasonic | Japan |
| - | Minitype photoelectricity inductor | PM-L44 | 2 | Panasonic | Japan |
| Driving unit | Driving servo motor | MHMD042P1U (400w) | 1 | Panasonic | Japan |
| - | Driving servo driver | MBDDT2210003 (400w) | 1 | Panasonic | Japan |
| Electric eye unit | High speed fibre-optical inductor | FX-300 | 1 | SUNX | Japan |
| Bottle monitor unit | Photoelectricity inductor | CX-442 | 1 | SUNX | Japan |
| Conveyor unit | Frequency converter | VFO-0.75KW | 1 | Schneider | France |
| - | Motor | RV50-30K-0.75KW | 1 | SANI | - |
| Electrical Counter | PLC integration module | AFPX-C60T | 1 | Panasonic | Japan |
| - | Touch screen | MT506-MV | 1 | WEINVIEW | Taiwan |
| - | Switch power source | MW-220-50-24 | 1 | Taiwan MingWei | Taiwan |
| - | Contactor | D1810 25A | 2 | Schneider | - |
| - | Socket | - | 1 | - | - |
| - | Intermediate relay | 10A | 3 | - | - |
| - | Fuse | 10A | 4 | - | - |
| - | Potentiometer | 0-10V | 4 | - | - |
| - | Emergency stop press button | - | 1 | - | - |
| - | Two selection switches | - | 1 | - | - |
| - | Button with guiding lights | - | 6 | - | - |
| - | 40 cores of arranging line terminal | JBOIDC40M | 2 | - | - |
| - | Emergency stop press button box | - | 1 | - | - |
| - | Transformer | 3KVA | 1 | - | - |
| Product Name | Specification | Quantity (root) | Remark |
|---|---|---|---|
| Driving belt | 5M -525-15 W | 1 | Largess |
| 5M -370-15 W | 2 | Largess | |
| Cutter head belt | 5M -525-15W | 1 | Largess |
| 5M -475-15W | 1 | Largess | |
| Hairbrush belt | 114XL*12W | 2 | Largess |
| Bottle carrying belt | 5M-230*10W | 2 | Largess |
| Cutter | - | 1 | Largess |
| Hairbrush | - | 1 | Largess |
Water is automatically fed into the electrical heating generator series via a durable high-pressure copper potential vortex pump. A floating ball inside the water tank controls water inlet automatic operation. Within approximately 5 minutes after connecting water and power, the system continuously outputs highly efficient steam.
30% deposit against contract by T/T before production. 70% balance paid by T/T after inspection and prior to delivery.
Delivery will occur within 60 days following the receipt of the down payment.
Technician training for machine operation can be arranged at the buyer's factory during the installation and adjusting phase upon request.
Reservations must be made in advance. Buyer bears visa application fees, round airfare tickets, food & lodging, plus USD 80/day per engineer.
All equipment is covered by a standard one-year warranty.
The machines utilize world-renowned brand components to ensure high performance and stability:
Qualified engineers are available on-site to guide installation, system debugging, and free personnel training. Dedicated support responds rapidly to product issues 24 hours a day, 7 days a week.
